Features of the Digital Check CheXpress CX30 Scanner With Endorser CX-30

*

*
Scanner Model: Digital Check CX-30
*
Feeder: Single Feed
*
Endorser: Yes
*
Scanner Dimensions:
*
Height: 7"
*
Depth: 4"
*
Length: 9.5"
*
Weight: 3.5 lbs.
*
Paper Size: Up to UNI A6
*
Document Height: 2.12"-4.17" (54-106mm)
*
Document Length: 3.19"-8.97" (80-228mm)
*
Document Weight: 16-120 lb. bond (60-500 grams/sq. meters)
*
(.09-.15mm thick)(.0035-.0059in thick)
*
Pass Through Mode: (.23mm thick)(.0090in thick)
*
Endorser:
*
12 dots/ch height.True Type Fonts support for multiple fonts and languages; supports graphical BMP printing
*
Estimated Yield: 5-7M characters
*
MICR:In-Line MICR Recogniti In-line MICR (Magnetic Ink Character Recognition) for E13B (North America) and CMC7 (Europe)
*
Optical Character Recognition to enhance Magnetic Read
*
Industry Best MICR Read Rate
*
Transport Speed: 19.7" (50 cm) per second. Up to 30 DPM
*
Scanning PerformanceThe typical scan speed is just over one second per 6" document
*
Standard Interface:
*
Standard USB 2.0 (recommended). Compatible with USB1.1 with performance limitations
*
Scan modes: Scan and Return, Exception Pass Through
*
Supported Compression
*
JPEG (24 bit for color, and 8 bit for grayscale)
*
BMP (24 bit for color, and 4 and 8 bit for grayscale)
*
Tiff Group 4 B/W

*
Image Resolution Optical
*
300x300 dpi - 8 bit Grayscale
*
300x100 dpi - 24 bit Color
*
Image Resolution by Software Scaling
*
240x240 (Scan at 300 dpi and scaling down to 240)
*
200x200 (Scan at 300 dpi and scaling down to 200)
*
120x120 (Scan at 300 dpi and scaling down to 120)
*
100x100 (Scan at 300 dpi and scaling down to 100)
*
Scanning Method: Concurrent two-sided duplex CIS
*
Image Creation: 2 x 1275 cell, 108mm CIS
*
Light Source: Tricolor LED
*
Diagnostic Features
*
Diagnostic Tools: Allows for full testing of scanner functionality
*
Recommended PC Configuration: 2 GHz, 1 GB RAM
*
Environmental, Reliability, & Electrical Features
*
Electric Power consumption: 24 Watts
*
Input Voltage: 100 to 240 VAC, 50/60hz
*
Separate Standard Power Supply Auto sensing for voltage
*
Product Life & Duty Cycle
*
Product Life: Designed for a useful life of over 1,000,000 items
*
Duty Cycle CX30: Up to 1500 items per day
*
Mean Time To Repair (MTTR): 15 minutes
*
Environmental:
*
Temp. (operating): 60° - 90° F (15° - 32° C)
*
Humidity (operating): 35-85% non-condensing
*
Certifications: UL, CE, FCC Class B, CEC IV, RoHS
*
