TE Connectivity Raychem CSTO-152G Cold Shrink Outdoor Termination

-

TE Connectivity Raychem CSTO-152G Cold Shrink Outdoor Termination quantity
SKU: CSTO-152GCategories: Cable Accessories, Cold Shrink Termination, TE Connectivity

* Description
* Additional information

Cold Shrink Termination (CST)

TE Connectivity (TE)'s Raychem Class 1 A CST cold shrink terminations are the one-piece solution for high performance in cold applied
terminations for polymeric cables up to 35 kV. CST offers a reliable, fast and easy-to-install system to ensure trouble-free service. All components are pre-expanded on an easy-to-remove spiral holdout, allowing installation in compact environments on prepared cable.

The silicone body is specially formulated for excellent tracking and erosion resistance. The extra-long stress cone aids in correct positioning
and integrated void-filling mastic eliminates the need for silicone grease. Sealing mastic for the lug end is built into the expanded termination
eliminating the need for additional sealing tapes. Shearbolt and compression style terminals and pin connectors are available to provide
reliable connection to a variety of conductors.

CST components have full traceability to raw materials and are in compliance with the following international standards:
IEEE-48, CENELEC HD 629.1.S2 (includes IEC, BS, VDE and other international specifications).

Key Features:

* Spiral holdout with pull direction toward the lug provides easy installation
* Extra-long, integrated geometric stress control and void-filling mastic to reduce termination positioning errors
* Outstanding weathering, UV and ozone resistance
* Chemical-resistant and fungus-resistant
* A mastic sealed version of the product is available for 25 kV/36 kV
* Hydrophobic silicone material to repel water
