Specifications Description

Our class 1 A Cold Shrink Terminations CST are the one-piece solution for high performance in cold applied terminations for polymeric cables up to 35 kV. Our CST offer a reliable, fast and easy-to-install system to ensure trouble-free service. Our components are pre-expanded on an easy-to-remove spiral holdout, allowing installation in compact environments on prepared cable. The silicone body is specially formulated for excellent tracking and erosion resistance. The extra-long stress cone aids in correct positioning and integrated void-filling mastic eliminates the need for silicone grease. Sealing mastic for the lug end is built into the expanded termination eliminating the need for additional sealing tapes. Shear bolt and compression style terminals and pin connectors are available to provide reliable connection to a variety of conductors.

Kit Type:Outdoor Cable Termination
Voltage Class:15 kV
Cable Type:Copper Tape Shield
Number of Terminations:1
Insulation OD - Min:0.97 in.
Insulation OD - Max:1.35 in.
Conductor Size - Min:350 MCM
Conductor Size - Max:500 MCM
