SuperMicro AOC-SIM2U-3B+ AOC-SIM1U-3D IPMI Remote Access

SMC Motherboards with AOC-SIM1U-3B Support
The following Supermicro motherboards support the AOC-SIM1U-3B/3B+ add-on card:
• The X7DBX/X7DBX-i Series
• The X7DBP-8/X7DB-P-i Series

Overview
The AOC-SIM1U-3B/AOC-SIM1U-3B+ add-on card is used in conjuction with its
AOC-SIM1U-3D daughter card. It offers a highly efficient, highly compatible and
easy-to-use IPMI card set that allows you to take advantage of the baseboard
management controller installed on a server motherboard (BMC). The BMC and
IPMIView, an IPMI-compliant management application software stored in a PC, can be
used to provide serial links between the main processor and other system components,
allowing for network interfacing via remote access. With an independent Raritan
KIRA100 processor built-in, the AOC-SIM1U-3B IPMI card set provides you with a
solution to ease the complex and expensive systems, allowing an administrator to
access, monitor, diagnose and manage network interfacing anywhere, anytime.
IPMI Version 2.0
The AOC-SIM1U-3B IPMI card set supports the functionality of IPMI Version 2.0. The
key features include the following:
• Supports IPMI 2.0 over LAN
• Supports Serial over LAN
• Supports KVM over LAN (For AOC-SIM1U-3B+ only)
• Supports Virtual Media over LAN
• Supports LAN alerting-SNMP trap
• Supports an Event Log
• Offers OS (Operating System) Independency

Remote Hardware Health Monitoring
The AOC-SIM1U-3B IPMI card set provides remote hardware health monitoring via
IPMI. Key features include the following:
• Temperature monitoring
• Fan speed monitoring
• Voltage monitoring
• Power status monitoring
• Chassis intrusion monitoring
• Remote power control to power-on, power-off or reboot a system
• Remote access to text-based, graphic-based system information, including BIOS
configurations and OS operation information (KVM)
• Remote management of utility/software applications
Network Management Security
The AOC-SIM1U-3B IPMI card set provides network management security via remote
access/console redirection. Key features include:
• User authentication enhancement
• Encryption support enhancement, allowing for password configuration security to
protect sensitive data transferring via Serial over LAN
• Supports the following Management tools: IPMIView, CLI (Command Line Interface)
• Supports RMCP and protocols

Product Features
The AOC-SIM1U-3B/AOC-SIM1U-3B+ series features the following:
• Slim size (4.4" W x 1.3" H) (111.76 mm W x 25.41 mm H)
• Supports IPMI over LAN
• Supports 1U and above
The AOC-SIM1U-3D daughter card features the following:
• Low profile (3.2" W x 2.4" H) (81.28 mm W x 60.96 mm H)
• Supports IPMI with a 3rd data dedicated LAN
• Supports a 3rd DATA LAN
